TL062 Dual Low-Power JFET-Input Op Amp by TI 200µA Supply 3.5V/µs Slew

Description

Product Overview

The TL062 is a dual operational amplifier that combines the low power consumption of a JFET-input stage with the performance needed for modern portable and battery‑powered designs. Each amplifier draws only 200 µA from the supply, allowing designers to keep overall system current well below the milliamps range while still achieving a slew rate of 3.5 V/µs. This speed is sufficient for most audio, sensor, and instrumentation applications where rapid signal transitions are required. The device operates from a single supply voltage ranging from 3 V to 36 V, and its common‑mode input range includes the positive rail, giving designers flexibility in single‑supply configurations. Internally, the TL062 includes short‑circuit protection on the output stage, preventing damage in the event of a load fault. The DIP‑8 package is specifically chosen for breadboard‑friendly prototyping, making it easy to test and integrate into development boards without the need for specialized sockets.

Usage

Engineers and hobbyists alike find the TL062 ideal for a wide variety of signal‑conditioning tasks. In portable medical devices, the low quiescent current helps extend battery life while the high slew rate ensures accurate waveform reproduction for ECG or pulse‑oximetry front‑ends. In audio equipment, the JFET input stage provides low noise and low bias currents, making the TL062 suitable for pre‑amplifier stages in mixers, guitar pedals, and headphone amplifiers. The wide input voltage range also allows the amplifier to be used in single‑supply sensor interfaces, such as thermocouple amplifiers, strain‑gauge bridges, and photodiode transimpedance stages. Because the device tolerates short‑circuit conditions, it can be safely employed in environments where accidental overloads may occur, such as robotics or automotive sensor modules. The DIP‑8 footprint simplifies integration into both hand‑wired prototypes and printed‑circuit‑board designs, enabling rapid iteration from concept to production.

Why Choose Us

Choosing the TL062 from Texas Instruments means selecting a component backed by decades of semiconductor expertise and a global support network. The amplifier is manufactured in facilities that adhere to stringent quality standards, ensuring each unit meets the specifications listed in the datasheet. TI provides comprehensive design resources, including reference schematics, application notes, and simulation models that accelerate development time. In addition, the company offers a robust warranty and responsive technical support, giving customers confidence that any design challenges can be addressed quickly. The TL062’s combination of low power, high slew rate, and built‑in protection distinguishes it from competing parts that may require additional external components to achieve the same level of performance. This integration reduces BOM cost and board space, which is critical in compact, cost‑sensitive products. Finally, the part’s long‑term availability guarantees that designs can be produced for many years without the risk of component obsolescence.

Key Features

• Ultra‑low 200 µA supply per amplifier extends battery life in portable devices.
• Fast 3.5 V/µs slew rate ensures accurate handling of rapid signal changes.
• JFET‑input stage provides low noise and low input bias for high‑precision applications.
• Built‑in short‑circuit protection safeguards the device against accidental overloads.
• Dedicated technical support and extensive design resources from Texas Instruments.

FAQ

What is the typical supply voltage range for the TL062?

The TL062 operates from a single supply voltage of 3 V to 36 V, making it versatile for both low‑voltage battery‑powered designs and higher‑voltage industrial applications.

Can the TL062 be used in single‑supply configurations?

Yes, the amplifier’s common‑mode input range includes the positive rail, allowing it to function effectively in single‑supply circuits without the need for dual‑rail power supplies.

How does the short‑circuit protection work?

The internal output stage includes a current‑limiting circuit that detects excessive load current and automatically reduces the output drive, preventing damage to the amplifier and the surrounding circuitry.

Is the TL062 suitable for audio pre‑amplifier applications?

Absolutely. The JFET‑input architecture delivers low noise and low input bias currents, which are essential for high‑fidelity audio pre‑amplifier stages, while the 3.5 V/µs slew rate supports the dynamic range required in professional audio equipment.

What resources does Texas Instruments provide for designing with the TL062?

TI offers a complete set of design tools, including SPICE models, reference schematics, application notes, and a community forum where engineers can ask questions and share design experiences.
